16 | Technical data
Installer reference guide
79
AZAS100~140MUV/Y
Sky Air Active-series
4P743509-1B – 2024.05
R2T Thermistor (discharge)
R3T Thermistor (suction)
R4T Thermistor (heat exchanger)
R5T Thermistor (heat exchanger middle)
R6T Thermistor (liquid)
R7T Thermistor (fin)
R8T~R10T (A1P ) Thermistor (PTC)
R11T (A1P ) (Y only) Thermistor (PTC)
R501~R962 (A1P ) (V only) Resistor
R2~R981 (A1P ) (Y only) Resistor
R*V (A2P ) (V only) Varistor
S1PH High pressure switch
S1PL Low pressure switch
SEG* (A1P) 7-segment display
TC1 (A1P) Signal transmission circuit
V1D (A1P) (V only) Diode
V1D~V2D (A1P) (Y only) Diode
V*R (A1P) Diode module/ IGBT power module
X*A Connector
X1M Terminal strip
Y1E, Y3E Electronic expansion valve
Y1S Solenoid valve (4‑way valve)
Y2S Solenoid valve (gas receiver)
Z*C Noise filter (ferrite core)
Z*F Noise filter
L*, L*A, L*B, NA, NB, E*,
U, V, W, X*A (A1P~A2P)
Connector
16.4 Eco Design requirements
Follow the steps below to consult the Energy Label – Lot 21 data of the unit and
outdoor/indoor combinations.
1 Open the following webpage: https://energylabel.daikin.eu/
2 To continue, choose:
▪ "Continue to Europe" for the international website.
▪ "Other country" for a country related site.
Result: You are directed to the "Seasonal efficiency" webpage.
3 Under "Eco Design – Ener LOT 21", click "Generate your data".
Result: You are directed to the "Seasonal efficiency (LOT 21)" webpage.
