8 | Electrical installation

Installer reference guide

AZAS100~140MUV/Y

Sky Air Active-series

4P743509-1B – 2024.05

8 Electrical installation

In this chapter

8.1 About connecting the electrical wiring .................................................................................................................................. 46

8.1.1 Precautions when connecting the electrical wiring .............................................................................................. 46

8.1.2 Guidelines when connecting the electrical wiring ................................................................................................ 47

8.1.3 About electrical compliance .................................................................................................................................. 49

8.2 Connections to the outdoor unit............................................................................................................................................ 49

8.2.1 Specifications of standard wiring components ..................................................................................................... 49

8.2.2 To connect the electrical wiring to the outdoor unit............................................................................................ 50

8.1 About connecting the electrical wiring

Typical workflow

Connecting the electrical wiring typically consists of the following stages:

1 Making sure the power supply system complies with the electrical

specifications of the units.

2 Connecting the electrical wiring to the outdoor unit.

3 Connecting the electrical wiring to the indoor units.

4 Connecting the main power supply.

8.1.1 Precautions when connecting the electrical wiring

DANGER: RISK OF ELECTROCUTION

WARNING

The appliance MUST be installed in accordance with national wiring regulations.

WARNING

▪ All wiring MUST be performed by an authorised electrician and MUST comply

with the national wiring regulation.

▪ Make electrical connections to the fixed wiring.

▪ All components procured on-site and all electrical construction MUST comply

with the applicable legislation.

WARNING

ALWAYS use multicore cable for power supply cables.

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[47].

INFORMATION

Also read "8.2.1Specifications of standard wiring components"[449].
