7 | Piping installation
Installer reference guide
34
AZAS100~140MUV/Y
Sky Air Active-series
4P743509-1B – 2024.05
(a)
Depending on the applicable legislation and the maximum working pressure of the unit
(see "PS High" on the unit name plate), larger piping thickness might be required.
7.1.3 Refrigerant piping diameter
Use the same diameters as the connections on the outdoor units:
L1 liquid piping Ø9.5mm
L1 gas piping Ø15.9mm
7.1.4 Refrigerant piping length and height difference
The piping length and height difference must comply with the following
requirements:
H1
L1
Requirement Limit
1 Minimum total one‑way piping length Limit≤L1 5m
2 Maximum total one‑way piping length L1≤Limit 30m (50m)
(a)
3 Maximum height between indoor and
outdoor
H1≤Limit 30m
(a)
Parenthesised figure represents the equivalent length.
7.1.5 Refrigerant piping insulation
▪ Use polyethylene foam as insulation material:
- with a heat transfer rate between 0.041 and 0.052 W/mK (0.035 and
0.045kcal/mh°C)
- with a heat resistance of at least 70°C for liquid piping and at least 120°C for
gas piping
▪ Insulation thickness:
Ambient temperature Humidity Minimum thickness
≤30°C 75% to 80% RH 15mm
>30°C ≥80% RH 20mm
7.2 Connecting the refrigerant piping
7.2.1 About connecting the refrigerant piping
Before connecting the refrigerant piping
Make sure the outdoor and indoor unit are mounted.
Typical workflow
Connecting the refrigerant piping involves:
▪ Connecting the refrigerant piping to the outdoor unit
