7 | Piping installation

Installer reference guide

AZAS100~140MUV/Y

Sky Air Active-series

4P743509-1B – 2024.05

7 Piping installation

In this chapter

7.1 Preparing refrigerant piping................................................................................................................................................... 33

7.1.1 Refrigerant piping requirements ........................................................................................................................... 33

7.1.2 Refrigerant piping material.................................................................................................................................... 33

7.1.3 Refrigerant piping diameter................................................................................................................................... 34

7.1.4 Refrigerant piping length and height difference................................................................................................... 34

7.1.5 Refrigerant piping insulation ................................................................................................................................. 34

7.2 Connecting the refrigerant piping.......................................................................................................................................... 34

7.2.1 About connecting the refrigerant piping............................................................................................................... 34

7.2.2 Precautions when connecting the refrigerant piping ........................................................................................... 35

7.2.3 Guidelines when connecting the refrigerant piping ............................................................................................. 36

7.2.4 Pipe bending guidelines ......................................................................................................................................... 36

7.2.5 To flare the pipe end.............................................................................................................................................. 36

7.2.6 To braze the pipe end ............................................................................................................................................ 37

7.2.7 Using the stop valve and service port.................................................................................................................... 38

7.2.8 To connect the refrigerant piping to the outdoor unit ......................................................................................... 39

7.3 Checking the refrigerant piping.............................................................................................................................................. 43

7.3.1 About checking the refrigerant piping................................................................................................................... 43

7.3.2 Precautions when checking the refrigerant piping ............................................................................................... 43

7.3.3 Checking refrigerant piping: Setup ........................................................................................................................ 44

7.3.4 To perform a leak test............................................................................................................................................ 44

7.3.5 To perform vacuum drying .................................................................................................................................... 44

7.1 Preparing refrigerant piping

7.1.1 Refrigerant piping requirements

NOTICE

The piping and other pressure-containing parts shall be suitable for refrigerant. Use

phosphoric acid deoxidised seamless copper for refrigerant piping.

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[47].

▪ Foreign materials inside pipes (including oils for fabrication) must be ≤30 mg/

10m.

7.1.2 Refrigerant piping material

▪ Piping material: phosphoric acid deoxidised seamless copper

▪ Flare connections: Only use annealed material.

▪ Piping temper grade and thickness:

Outer diameter (Ø) Temper grade Thickness (t)

(a)

6.4mm (1/4")

9.5mm (3/8")

12.7mm (1/2")

Annealed (O) ≥0.8mm

15.9mm (5/8") Annealed (O) ≥1.0mm

19.1mm (3/4") Half hard (1/2H)
