12 | Commissioning
Installer reference guide
65
2MXM-A8, 3MXM-A8, 4MXM-A8, 5MXM-A8
R32 Split series
4P766272-5C – 2025.05
2 Press shortly the wiring error check switch (SW3) on the outdoor unit service
PCB.
Result: The service monitor LEDs indicate whether correction is possible or
not. For details about how to read the LED display, refer to the service
manual.
Result: Wiring errors will be corrected after 15-20minutes. If automatic correction
is not possible, check the indoor unit wiring and piping in the usual way.
INFORMATION
▪ The number of LEDs displayed depends on the number of rooms.
▪ The wiring error check function will NOT work if outside temperature is ≤5°C.
▪ After wiring error check operation is completed, LED indication will continue until
normal operation starts.
▪ Follow the product diagnosis procedures. For details of product error diagnosis
refer to service manual.
Status of LEDs:
▪ All LEDs flash: automatic correction is NOT possible.
▪ LEDs flash alternately: automatic correction is completed.
▪ One or more LEDs are permanently on: abnormal stop (follow the diagnosis
procedure on the back of the right side plate and refer to service manual).
12.5.2 To perform a test run
INFORMATION
If the unit runs into an error during commissioning, see the service manual for the
detailed troubleshooting guidelines.
Prerequisite: Power supply MUST be in the specified range.
Prerequisite: Test run operation may be done in cooling or heating mode.
Prerequisite: Test run should be done in accordance with the operation manual of
the indoor unit to make sure that all functions and parts are working properly.
1 In cooling mode, select the lowest programmable temperature. In heating
mode, select the highest programmable temperature.
2 Measure the temperature at the indoor unit inlet and outlet after running the
unit for about 20minutes. The difference should be more than 8°C (cooling)
or 20°C (heating).
3 First check operation of each unit individually, then check simultaneous
operation of all indoor units. Check both heating and cooling operation.
4 When test run is finished, set the temperature to a normal level. In cooling
mode: 26~28°C, in heating mode: 20~24°C.
