7 | Piping installation

Installer reference guide

2MXM-A8, 3MXM-A8, 4MXM-A8, 5MXM-A8

R32 Split series

4P766272-5C – 2025.05

7 Piping installation

In this chapter

7.1 Preparing refrigerant piping................................................................................................................................................... 32

7.1.1 Refrigerant piping requirements ........................................................................................................................... 32

7.1.2 Refrigerant piping insulation ................................................................................................................................. 33

7.1.3 Refrigerant piping length and height difference................................................................................................... 34

7.2 Connecting the refrigerant piping.......................................................................................................................................... 35

7.2.1 About connecting the refrigerant piping............................................................................................................... 35

7.2.2 Precautions when connecting the refrigerant piping ........................................................................................... 35

7.2.3 Guidelines when connecting the refrigerant piping ............................................................................................. 37

7.2.4 Pipe bending guidelines ......................................................................................................................................... 37

7.2.5 To flare the pipe end.............................................................................................................................................. 37

7.2.6 Connections between outdoor and indoor unit using reducers........................................................................... 38

7.2.7 Using the stop valve and service port.................................................................................................................... 41

7.2.8 To connect the refrigerant piping to the outdoor unit ......................................................................................... 42

7.3 Checking the refrigerant piping.............................................................................................................................................. 43

7.3.1 About checking the refrigerant piping................................................................................................................... 43

7.3.2 Precautions when checking the refrigerant piping ............................................................................................... 43

7.3.3 To check for leaks................................................................................................................................................... 43

7.3.4 To perform vacuum drying .................................................................................................................................... 44

7.1 Preparing refrigerant piping

7.1.1 Refrigerant piping requirements

CAUTION

Piping and joints of a split system shall be made with permanent joints when inside

an occupied space except joints directly connecting the piping to the indoor units.

NOTICE

The piping and other pressure-containing parts shall be suitable for refrigerant. Use

phosphoric acid deoxidised seamless copper for refrigerant piping.

INFORMATION

Also read the precautions and requirements in the "2 General safety

precautions"[47].

▪ Foreign materials inside pipes (including oils for fabrication) must be ≤30 mg/

10m.

Refrigerant piping diameter

2MXM68

Liquid piping 2× Ø6.4mm (1/4")

Gas piping 1× Ø9.5mm (3/8")

1× Ø12.7mm (1/2")

3MXM40, 3MXM52, 3MXM68

Liquid piping 3× Ø6.4mm (1/4")

Gas piping 1× Ø9.5mm (3/8")

2× Ø12.7mm (1/2")
