Distributed Series | NEB0105HI-4K

www.dahuasecurity.com

Features：

· Support 1ch DP, 1ch HDMI independent collecon

interfaces,Support 4K and H.265 real-me encoding

· Powerful 10M/100M/1000M self-adapve Ethernet

interface

· Support TCP/IP/RTP/RTSP/HTTP/TCP/UDP/DHCP/NTP and etc.

network protocols

· Remote reboot/upgrade/default seng and etc. operaons

· Provides SDK, demo software and development manual

· Supports 1-channel HDMI loop output and 1-channel HDMI

output

· Supports redundant power input of two channels: PoE and

12 VDC

NEB0105HI-4K

1 Channel Distributed Encoding Box

Technical Speciﬁcaon

Model

Model NEB0105HI-4K

System Parameter

System Processor

High-performance industrial embedded micro processor

Embedded LINUX

Interface

Video Input 1 HDMI1.4 (support DVI with convertor), 1 DP

Video Output 1 HDMI2.0 and 1 HDMI loop output

Audio Input 1 HDMI and DP (embedded), 1 3.5mm jack

Intercom

1 3.5mm jack earphone (reserved)

1 3.5mm jack microphone (reserved)

Alarm In/Out 2/2（30VDC 1A,125VAC 0.5A linkage out）

Network Port 1 RJ45 10/100/1000M self-adaptive ethernet interface

RS232 1 RS232(DB9)

USB 1 USB 2.0, 1 USB （reserved）

RS485 1 RS485

Performance

Encoding Capacity Access Resolution

HDMI/DP：4096x2160/3840x2160/256

0x1440/1920x1080/1280x1024/1280x9

60/1280x720/1024x768

Encoding Capacity

Video Frame Rate

1~60fps, 4096×2160 max supports

24fps, 3840×2160 max supports 30fps

Encoding Capacity

4096×2160@24fps,3840×2160@30fps,

2560×1440@60fps,1920×1080@60fps,

1280×1024@60fps,1280×960@60fps,1

280×720@60fps,1024×768@60fps

Video Encoding

Format

H.265/H.264（default H.264）

Audio Encoding

Format

G.711a

Stream Type Composite stream, video stream

Protocol RTSP;Private

Others

Working Environment

Operating

temperature

-10℃~+55℃

Humidity 10%~90%, 86kpa~106kpa

Consumption ≤10W

Dimension

45mm×153.8mm×100mm(1.77× 6.06× 3.93 inch),

(H*D*W)

Power DC12V,2.0A;POE

Weight 0.65kg (1.43 Ib)

HDMI

Collection

H.265

Linux
