Operation Manual
57
Figure 6-44 Multicast
Step 2 C
lick , and enter IP address and port number.
Table 6-18 Description of multicast parameters
Parameter Description
Multicast Address
The multicast IP address of Main Stream/Sub Stream is
224.1.2.4 by default, and the range is 224.0.0.0–
239.255.255.255.
Port
The multicast port of corresponding stream: Main Stream:
40000; Sub Stream1: 40016; Sub Stream2: 40032, and all the
range is 1025–65500.
Step 3 Click Apply.
Result
On the Live page, select RTSP in Multicast, and then you can view the video image with
multicast protocol.
6.3.10 Register
After you enable this function, when the camera is connected into Internet, it will report the
current location to the specified server which acts as the transit to make it easier for the client
software to access the camera.
Procedure
Step 1 Select > Network > Register.
Figure 6-45 Register
Step 2 C
lick , and then configure server name.
