Operation Manual
55
password and authentication type to visit your device from the server.
Using V1 and V2 might cause data leakage, and V3 is recommended.
Step 3 I
n Trap Address, enter the IP address of the PC that has MIB Builder and MG-SOFT
MIB Browser installed, and leave other parameters to the default.
Table 6-17 Description of SNMP parameters
Parameter Description
SNMP Port The listening port of the software agent in the device.
Read Community, Write
Community
The read and write community string that the software agent
supports.
You can enter number, letter, underline and dash to form the
name.
Trap Address
The target address of the Trap information sent by the
software agent in the device.
Trap Port
The target port of the Trap information sent by the software
agent in the device.
Read-only Username
Set the read-only username accessing device, and it is public
by default.
You can enter number, letter, and underline to form the
name.
Read/Write Username
Set the read/write username access device, and it is private by
default.
You can enter number, letter, and underline to form the
name.
Authentication Type You can select from MD5 and SHA. The default type is MD5.
Authentication Password It should be no less than 8 digits.
Encryption Type The default is CBC-DES.
Encryption Password It should be no less than 8 digits.
Step 4 Click Apply.
Result
View device configuration through MIB Builder or MG-SOFT MIB Browser.
1. Run MIB Builder and MG-SOFT MIB Browser.
2. Compile the two MIB files with MIB Builder.
3. Load the generated modules with MG-SOFT MIB Browser.
4. Enter the IP address of the device you need to manage in the MG-SOFT MIB Browser, and
then select version to search.
5. Unfold all the tree lists displayed in the MG-SOFT MIB Browser, and then you can view the
