Operation Manual
115
maximum size of the target. Only when the target size is between the maximum
size and the minimum size, can the alarm be triggered.
●
Click , and then press and hold the left mouse button to draw a rectangle, the
pixel size is displayed.
●
Click to delete the detection line.
Step 6 Set parameters.
Table 8-2 Description of face detection parameters
Parameter Description
OSD Info
Click OSD Info, and the Overlay page is displayed, and then enable
the face statistics function. The number of detected faces is
displayed on the Live page. For details, see "6.2.2.2.12 Configuring
Face Statistics".
Face Enhancement
Click to enable face enhancement, and it can preferably
guarantee clear face with low stream.
Non-living Filtering Filter non-living faces in the image, such as a face picture.
Target Box Overlay
Click to enable the function, and then you can add a
bounding box to the face in the captured picture to highlight the
face.
The captured face picture is saved in SD card or the configured
storage path. For the storage path, see "6.1 Local".
Remove Duplicate
Faces
During the configured period, the duplicate faces are displayed
only once to avoid repeated counting.
Click to configure the parameter, and then click Apply.
●
Time: During the configured time, the function is enabled.
●
Precision: The larger the precision value, the higher the
accuracy.
Face Cutout
Set a range for the captured face image, including face, one-inch
picture, and custom.
When selecting Custom, click , configure the parameters on the
prompt page, and then click Apply.
●
Customized width: Set snapshot width; and then enter the times
of the original face width. It ranges from 1–5.
●
Customized face height: Set face height in snapshot; and then
enter the times of the original face height. It ranges from 1–2.
●
Customized body height: Set body height in snapshot; and then
enter the times of the original body height. It ranges from 0–4.
When the value is 0, it cuts out the face image only.
