Operation Manual
44
Parameter Description
Gamma
Changes the picture brightness and improves the picture dynamic
range in a non-linear way. The higher the value is, the brighter the
picture will be, and the smaller the darker.
Mirror
Select
On
, and the picture would display with left and right side
reversed.
Flip
Changes the display direction of the picture, see the options below.
●
0°: Normal display.
●
90°: The picture rotates 90° clockwise.
●
180°: The picture rotates 90° counterclockwise.
●
270°: The picture flips upside down.
For some models, please set the resolution to be 1080p or lower when
using 90° and 180°. For details, see "4.5.2.1 Video".
EIS
Corrects the device shaking with difference comparison algorithm and
improves the image clarity, effectively solves the picture shaking
problem.
Optical Dejitering
The lens vibration is sensed by the gyroscope sensor, and the
corresponding compensation is calculated using the intelligent
anti-shake algorithm. The movable parts inside the lens are driven to
offset the vibration, which greatly reduces blurring of the image caused
by the vibration.
Picture Freeze
When you call a preset, the image displays the preset location, not the
rotation image.
Step 3 Click
Save
.
4.5.1.1.3 Exposure
Configure iris and shutter to improve image clarity.
Cameras with true WDR do not support long exposure when WDR is enabled in
Backlight
.
Step 1 Select
Setting
>
Camera
>
Conditions
>
Conditions
>
Exposure
.
Figure 4-35 Exposure
