25
1. Handle
2. Throttle shift assy
3. Handle grips
4. Power switch
5. Clutch grip
6. Hexagon headed bolt M16*150
7. "T" shape handle lock
8. Washer 20
9. Spring wahser 20
10. Plate
11. Washer 16
12. Standard spring washer 16
13. High&low position handle lock
14. Rubber handle
15. Clutch cable
16. Pin
17. Washer
18. Standard spring washer 10
19. Bolt M10×95
20. Bolt M10×95
21. Connection part assy
22. Pin Ф3.0
23. pin B8*50
24. Connection frame assy
25. Speed control bar
26. PinФ2.0
27. Bolt M12*60
28. Nut M12
29. Nut M10
30. Handle seat
31. Bolt M8*20
32. Gasket
33. Pin B5*28
34. Pin 1.6*20
35. Gear shift indicator
36. Bolt M6*12
37. Shift lever
38. Pulley bottom plate
39. Bolt M8*40
40. Belt cover support bracket
41. Driven pulley
42. Pulley cover
43. Bolt M6X16
44. Bolt M8X40
45. Belt 17*963
46. Belt cover
47. Pin B6*35
48. Bolt M8*16
49. Right fender
50. Blade assy
51. Gear box assy
52. Rear support frame Fender
53. Nut M8
54. Washer 8
55. Tension pulley support shaft
56. Washer 6
57. Tension pulley spring
58. Tension pulley assy
59. Belt cover subframe
60. Bolt M6*16
61. Nut M8
62. Spring wahser 8
63. Washer 8
64. Left fender
65. Bolt M10X70
66. Engine support bracket
67. Bumper
68. Stand rod junction plate
69. Bolt M10X80
70. Spring
71. Stand rod
72. Front support frame Fender
73. Bolt M8*60
74. Engine
75. Belt cover support bracket
76. Belt cover subframe
77. Drive pulley
78. Bolt M8X35
79. Throttle cable
