To the side walls
1. Put a large towel on the bottom of
the dishwasher (covering the sump) to
prevent wood shavings or screws from
falling into the dishwasher sump.
3
/16" (5 mm)
2. To prevent damage to the drain hose
through the water supply line, slightly
pull out the dishwasher and bend the
built-in ear brackets of the left and
right housings by
3
/16" (5 mm). When
done, reinsert the dishwasher with its
center aligned.
NOTE
Skip this process if you have performed it
in Step 2 above.
3. Drill one hole into both sides of the
kitchen cabinet, totaling 2 screw holes.
• Make sure the hole you drill is smaller
than the diameter of the screw.
• Make sure the drill bit does not strike
the sides of the spacer cap holes.
4. Tighten the provided screws into the
holes to secure the dishwasher to the
cabinet.
5. Insert the provided plastic caps to the
4 places where screws are fastened.
English28
Installation
Installation
DD68-00250L-00_IB_DACOR_DW8700B_EN.indd 28 2024-01-11 3:09:30
