157D-Link ShareCenter Pro 1200-05 User Manual

Section 3 - Conguration

Network

Click the Network icon in the System Management window or the Network link in the left window to congure the Network.

LAN 1

Click the LAN 1 tab to see the following window.

DHCP Client Click the radio button to obtain the IP address from

a DHCP server.

Static IP Click the radio button to assign a static IP address to

the ShareCenter Pro.

IP Address Enter a static IP address.

Subnet Mask Enter the subnet mask for the IP address.

Jumbo Frame Use the drop-down menu to select the larger

frame size than standard Ethernet frame size.

Gateway Enter the gateway IP address

for the ShareCenter Pro.

VLAN Enable or disable the VLAN.

VLAN ID Enter a VLAN ID when VLAN is enabled.

Port Bonding Enable or disable port bonding which

is also known as port trunking.

Option Use the drop-down menu to select the

port bonding method. Available methods

are Round Robin, Active Backup, XOR,

Broadcast, 802.3ad, Adaptvie Transmit Load

Balancing, and Adaptive Load Balancing.

Click Apply to save the settings.
