DIS-200G Series Industrial Gigabit Ethernet Smart Managed Switch
23
Jumbo Frame
This window is used to view and configure the Jumbo Frame size and settings. The Switch supports
jumbo frames. Jumbo frames are Ethernet frames with more than 1,518 bytes of payload. The Switch
supports jumbo frames with a maximum frame size of up to 9600 bytes.
To view the following window, click System > Port Configuration > Jumbo Frame, as shown below:
The fields that can be configured are described below:
Parameter Description
From Port / To Port
Select the appropriate port range used for the configuration here.
Maximum Receive Frame Size
Enter the maximum receive frame size value here. This value must
be between 1518 and 9600 bytes. By default, this value is 1518
bytes.
Click the Apply button to accept the changes made.
Figure 4-6 Jumbo Frame window
