6
ANT24-0700 Install GuideSystem Requirements
ANT24-0700 Install Guide
System Requirements
ANT24-Series
D-Link ANT24-0500
Indoor/Outdoor
Omni-Directional Antenna
Electrical specifi cation
Environmental & Mechanical Characteristics
Survival wind speed 180 km/hr
Temperature -40 C to +80 C
Humidity 100% @ 25 C
Lightning protection DC ground
Radome color Gray-white
Radome material Fiberglass
Radiator material Micro striple line
Weight 0.8kgw
Dimensions 330 x 19 mm
Omni-Directional Antenna
for 2.4 GHz
SAA04-050170
Frequency range 2400 MHz - 2500 MHz
Gain 5.0 dBi
VSWR 2.0 : 1 Max.
Polarization Linear, vertical
HPBW / horizontal 360
o
HPBW / vertical 32
o
Downtilt 0
o
Power handling 20 W (cw)
Impedance 50 Ohms
Connector SMA Plug
Cable ULA 168, 100cm
Electrical Specification
Environmental & Mechanical Characteristics
Temperature - 10
o
C to +55
o
C
Humidity 95% @ 25
o
C
Lightning protection DC ground
Radome color Gray-white
Radome material Fiberglass, UV resistant
Weight 0.8kg
Dimensions φ19 x 330 mm
90
o
180
o
150
o
120
o
60
o
30
o
0
o
-150
o
-90
o
-120
o
-60
o
-30
o
-3
-10
-20
-30
Version 1
H-plane Co-polarization Pattern
90
o
180
o
150
o
120
o
60
o
30
o
-150
o
-90
o
-120
o
-60
o
-30
o
-3
-10
-20
-30
V-plane Co-polarization Pattern
0
o
http:// www.smartant.com TEL: +886 (0)3 578-3188 FAX: +886 (0)3 578-3189 E-mail: service@smartant.com
All right reserved by SmartAnt Telecom Co., Ltd.
P1
EMW2403005AMLM01
32
Ø19×330mm
