11
EDID
ON
1
23
4
1
1
EDID: The EDID dipswitch block provides a way to select the EDID
to use with the connected source. By using a combination of on and
off settings for the dipswitches, there are a total of 16 possible EDID
selections across 3 different operation modes.
The three modes are “Internal EDID”, “User EDID” and “External EDID”.
There are a total of 6 built-in internal EDIDs and 9 User EDIDs (which
can be modified via USB upload). The “External EDID” setting will copy
the EDID from the sink that is connected to the Receiver. (See “EDID
Management” for more details.)
6.4 IR Cable Pinouts
3
1
2
Infrared
Power
Ground
IR Extender
3
1
2
IR Blaster
Power
Infrared
NC
