20
5) Firmware Upgrade: To update the unit's firmware, click the
“Choose File” button to open the file selection window and then
select the firmware update file (*.bin format) located on your local
PC. After selecting the file, click the “Upgrade” button to begin the
firmware update process. Once the process completes the unit will
automatically reboot.
6.4 Serial Control (Via Receiver)
Serial Port Default Settings
Baud Rate 19200
Data Bits 8
Parity Bits None
Stop Bits 1
Flow Control None
Note: RS-232 support requires the use of a compatible HDBaseT Receiver with
an RS-232 bypass port.
6.5 Telnet Control
Before attempting to use Telnet control, please ensure that both the unit
and the PC are connected to the same active networks.
To Access the Command Line Interface (CLI)
Windows 7 Click Start, type “cmd” in the search eld, and press
Enter.
Windows XP Click Start > Run, type “cmd”, and press Enter.
Mac OS X Click Go > Applications > Utilities > Terminal.
Once in the Command Line Interface (CLI) type “telnet” followed by the
IP address of the unit (and the port number if it is non-standard) and then
hit “Enter”. This will connect us to the unit we wish to control.
Microsoft Windows [Version 6.1.7601]
Copyright (c) 2009 Microsoft Corporation. All rights reserved.
C:\Users\Adminstrator\telnet 192.168.1.50 23
Note 1: If the IP address is changed then the IP address required for Telnet access will
also change accordingly.
Note 2: The default IP address is 192.168.1.50.
