10
3
HDMI IN Port: Connect to HDMI source equipment such as a media
player, game console, or set-top box.
4
DP IN Port: Connect to DisplayPort source equipment such as a PC or
laptop.
5
CAT.5e/6/7 OUT Port: Connect to a compatible HDBaseT Receiver
with a single Cat.5e/6/7 cable for transmission of all data signals. PoH
will also be supplied to a connected compatible PD Receiver.
6
IR EXTENDER Port: Connect to an IR Extender to receive IR control
signals and extend them to devices connected to the other end of
the HDBaseT connection. Ensure that the remote being used is within
direct line-of-sight of the IR Extender.
7
IR BLASTER Port: Connect to the provided IR Blaster to transmit IR
signals from the other end of the HDBaseT connection to devices
within direct line-of-sight of the IR Blaster.
8
RS-232 CONSOLE Port: Connect directly to a PC, laptop, or other
serial control device with a 3-pin adapter cable to send RS-232
commands to control the unit.
RS-232 BYPASS Port: Connect to a PC, laptop, or other serial control
device with a 3-pin adapter cable for the extension of RS-232 signals
to the Receiver.
9
DC 24V Port: Plug the 24V DC power adapter into this port and
connect it to an AC wall outlet for power.
