CYP PU-8H8HBTPL-4K22 handleiding
Handleiding
Je bekijkt pagina 7 van 24
7
5. FEATURES
HDMI, HDCP 1.1 and DVI compliant
Supports resolutions VGA~WUXGA, 4K2K@24/25/30Hz & YUV_420 @60Hz
and 480i~1080p dependent upon the output display’s EDID settings
Supports uncompressed video/audio up to 10.2Gbps
Supports LPCM 7.1CH, Dolby TrueHD, Dolby Digital Plus and DTS-HD
Master Audio transmission
Supports distances up to 60 meters through CAT6/7 cables
Supports 3D signal display dependent upon the output display EDID
settings
Supports PoC (Power over Cable) on compatible receivers only
Supports HDMI input up to 15 meters at 8-bit resolution or 10 meters at
12-bit resolution
Supports bi-directional IR from input and output locations
Supports RS-232, remote control, on-panel control and IP Control (Telnet
& Web GUI)
2U size design
upports external and internal EDID settings
Supports RS-232 for Matrix Control, plus RS-232 pass-through: Third-party
devices can be controlled in each zone via RS-232 from the head-end to
the receiver, or head-end devices can be controlled via RS-232 from any
receiver in any zone
Supports CEC control function of both sources and screens using Telnet,
Web GUI or RS232
Note:
1. The PoC function is designed for powering compatible receiver units only—non-PoC
receivers will need their own power supply. Receivers of another brand may not be
compatible.
2. Do not connect the LAN port to CAT outputs of this device or to CAT inputs or
receiver. Doing so may damage the unit.
Bekijk gratis de handleiding van CYP PU-8H8HBTPL-4K22, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | CYP |
| Model | PU-8H8HBTPL-4K22 |
| Categorie | Niet gecategoriseerd |
| Taal | Nederlands |
| Grootte | 3065 MB |
Caratteristiche Prodotto
| Kleur van het product | Zwart |
| Gewicht | 4520 g |
| Breedte | 440 mm |
| Diepte | 265 mm |
| Hoogte | 90 mm |
