8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SERVICE POWER 123
OUT A
123
OUT B
PRO-F32M
1 2 3 4 5 6
1
SERVICE: This slot is reserved for firmware update use only.
2
IR WINDOW: Accepts IR signals from the included IR remote for
control of this unit only.
3
POWER LED: This LED will illuminate green to indicate the unit is on
and receiving power. When the unit is in stand-by mode the LED will
illuminate red.
4
POWER BUTTON: Press this button to power the unit on or place it
into stand-by mode.
Note: Ethernet, IR and RS-232 remain active while the unit is in stand-by
mode.
5
OUT A BUTTON & LEDs: Press this button to sequentially switch
through the 3 available inputs, and mute, for Output A. The LEDs will
illuminate to indicate the currently selected input for Output A. When
all 3 LEDs are blinking, the output is muted.
6
OUT B BUTTON & LEDs: Press this button to sequentially switch
through the 3 available inputs, and mute, for Output B. The LEDs will
illuminate to indicate the currently selected input for Output B. When
all 3 LEDs are blinking, the output is muted.
