6
1. INTRODUCTION
This 4K UHD 8 by 8 Matrix provides the ability to connect up to eight 4K
UHD HDMI sources to up to eight 4K UHD HDMI displays and freely switch
between them. This unit comes with full support for 18Gbps (600Mhz)
resolutions up to, and including 4K@60Hz (RGB & YUV 4:4:4, 8-bit). With
a comprehensive EDID management feature that includes the ability
to select between built in default EDID, EDID copied from connected
sink devices, as well as a configurable EDID, this matrix can solve many
interconnectivity problems.
This unit also features eight USB ports which supply up to 5V/1A power
for use with connected AOC (Active Optical Cable) fiber cable extenders.
By using these specialised cables your HDMI content can be extended
much further than would be possible with normal HDMI cables. The built-
in OSD has the ability to display user editable general information text
so each output can display up to 2 lines of customised text on top of the
video source in the colour of your choice. This unit provides an intuitive
set of front panel controls with an LCD as well as RS-232, Telnet, WebGUI,
and IR remote control options.
2. APPLICATIONS
Smart Home Control
Control Center
Function Room
Product Showroom
Ballroom
3. PACKAGE CONTENTS
1×8 by 8 HDMI Matrix
1×Remote Control (CR-177)
1×IR Extender Cable
1×24V/6.25A DC Power Adaptor
1×Power Cord
1×Rack Mount Ears (Set of 2)
1×Operation Manual
4. SYSTEM REQUIREMENTS
