8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
POWERA
A
1
2
3
4
1
2
3
4
B
BH
DMI IN
HDMI IN / OUT
1
1 2 3 4 5 6
1
IR window: Accepts IR signals from the included IR remote for control
of this unit only.
2
POWER: Press this button to power on the unit or place it into stand-
by mode.
Note: Ethernet and RS-232 remain active while the unit is in stand-by
mode.
3
Power indicator: This LED will illuminate GREEN to indicate the unit
is on and receiving power. When the unit is in stand-by mode the LED
will illuminate RED.
4
HDMI Out routing buttons “A” & “B”: Press either of these buttons
to sequentially switch through the available inputs for the associated
output.
5
HDMI In indicator “1&2&3&4”: The LED in each column will
illuminate GREEN to indicate which source is currently selected for
each output
6
HDMI In: Connect to HDMI source equipment such as a media player,
game console or set-top box. DVI sources are also supported with the
use of an HDMI to DVI adapter.
