LINE IN Port: Connect to the stereo analogue output of the device
connected to the VGA input port.
6
HDMI A OUT Port: Connect to an HDMI TV, monitor, or amplier for
digital video and audio output.
7
HDMI B OUT Port: Connect to an HDMI TV, monitor, or amplier for
digital video and audio output.
Note: Audio on this output is not controllable and is bypass only.
8
RS-232 CONSOLE 3-pin Terminal Block: Connect directly to a PC,
laptop, or other serial control device with a 3-pin adapter cable to
send RS-232 commands to control the unit.
9
DC 24V Port: Plug the 24V DC power adapter into this port and
connect it to an AC wall outlet for power.
10
USB 3.0 Host Port (Type-B): Connect directly to a standard USB host
such as a PC or laptop to extend their USB functionality to all currently
connected USB devices.
11
SERVICE Port: Connect directly to a standard USB device such as a
mouse, keyboard or ash drive to extend their USB functionality to
the currently active USB Host Port. This port may also be used to apply
rmware updates.
12
LAN Port: Connect directly, or through a network switch, to your PC/
laptop to control the unit via Telnet/WebGUI.
13
TRIGGER IN 10-pin Terminal Block: Connect to the Trigger Control
Keypad (OPTIONAL) or any device with trigger switch functionality
such as window security alarms, motion detectors, door switches, etc.
Each of the 8 triggers will activate an assigned unit function when
triggered.
Note: A minimum of 5V DC is required to activate a trigger
14
AUDIO OUT R & L Ports: Outputs audio extracted from Output A’s
current source (LPCM 2.0 sources only). Connect to powered speakers
or an amplier for stereo analogue audio output.
15
AMPLIFIER OUT R & L 2-pin Terminal Blocks: Connect to unpowered
4Ω speakers for analogue stereo audio output. Up to 20W of power is
provided to each speaker.
