6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
1 234 1 234
ZONE
BAARC
IR SERVICEZONE AZONE BAUDIO SELECT MUTE Vol –Vol +POWER
MA-421
1 2 3
4 5
6
7 8
1
POWER Button and LED: Press this button to power the unit on (green
LED) or place it into standby mode (red LED).
Note: If the IR Auto Power Control function is turned on for any inputs/
outputs, this button will also turn on/off those devices that have IR
commands stored.
2
ZONE A Button and LEDs: Press this button to sequentially switch
through the available inputs for Zone A. The LED will illuminate to
indicate which source is currently selected.
Note: The selected input will also be displayed on the mirrored HDMI
output.
3
ZONE B Button and LEDs: Press this button to sequentially switch
through the available inputs for Zone B. The LED will illuminate to
indicate which source is currently selected.
4
ANALOGUE AUDIO Button and LEDs: Press this button to
sequentially switch through the available audio sources for both
analogue outputs. The LED will illuminate to indicate which source is
currently selected. The available sources are: Zone A’s current input,
Zone B’s current input, ARC audio from the HDMI output.
Note: If the display connected to the HDMI output does not support ARC,
no audio will be heard when the ARC source is selected.
5
MUTE Button and LED: Press to toggle between muting and
unmuting the analogue audio output. The LED will illuminate when
mute is active.
Note: By default, the mute button only controls the amplified output. This
behavior can be adjusted via RS-232.
