31
6.6.4 Transmitter Tab
This tab shows all transmitters that have been detected by the unit.
Details about each transmitter’s name, IP address, and video content, as
well as options to configure the network, RS-232, USB, and general device
settings are also provided.
Note: Units that were previously a part of the system, but are not currently
detected, will still be displayed; however, they will have a disconnected icon
( ) and cannot be used for routing. These units may be removed from the list
using the “Remove” button.
1) Transmitter Configuration:
Remove: Click on this button to remove any transmitter from
the list that has the disconnected icon (
). The pop-up window
provides a dropdown to select the unit to be removed. Once the
selection has been made, click on “Confirm” to apply the change.
Note: Only disconnected transmitters can be removed here.
Hello: Clicking on this switch will cause the selected unit to
immediately begin flashing the LEDs on the front of the unit to
make it easy to find. Clicking it a second time returns the LEDs to
their normal behavior.
Icon: Displays the icon used to represent the unit.
Order: Use the dropdown to reorder the units in the list. Changing
the order here will also change the order the units are listed in
other tabs.
Name: Displays each unit’s currently assigned name.
Note: The name can be changed within “Device Settings”.
