21
LOGO SETTINGS
2ND LEVEL 3RD LEVEL
Logo On/O On
OFF
Position X 0~100 (10)
Position Y 0~100 (10)
Load Default Logo NO
Yes
Logo Update NO
Yes
1) Logo On/O: Enable or disable displaying the logo graphic.
2) Position X/Y: Sets the position of the logo’s upper left corner, within
the output. The position values are a relative percentage of the
available output resolution.
3) Load Default Logo: Selecting yes will reset the logo and install a
default test image.
Note: The reset process can take a few moments. Progress information
will be displayed on the OSD while the default logo is being installed. The
unit will automatically reboot when it is finished.
4) Logo Update: To upload a graphic logo via USB, select “Yes” and then
insert a USB stick containing the new logo graphic file (8-bit *.BMP
format, 960×540 max resolution) into the Service port. The upload will
occur immediately.
Note: The USB stick must contain, in the root directory, a compatible and
properly named (Logo_User_*.BMP) graphic file.
