24
AUDIO
2
ND
LEVEL 3
RD
LEVEL 4
TH
LEVEL
Analog Out Mute OFF
On
Speaker Out Mute OFF
On
1) HDMI Out Bypass: Enable or disable HDMI audio bypass mode. When
enabled, all audio will automatically behave as if in “Follow Video”
mode and bitstream audio can be supported.
Note: This bypass setting affects audio only.
2) Audio Routing: Select the audio routing behaviour of the unit.
■
Follow User: Audio routing will follow the selections made in the
“Follow User Setting” section.
■
Follow Video: All digital sources will use their native embedded
audio content. VGA 1 will use the Analogue 1 audio input and VGA
2 will use the Analogue 2 audio input.
■
Fixed Analog 1~6: Forces all video sources to be paired with the
selected analogue audio source.
Note: When HDMI Out Bypass for audio is enabled, all audio will
automatically behave as if in “Follow Video” mode.
3) Follow User Setting: Options for defining the audio routing to use
when the “Follow User” mode is enabled. Select the preferred Follow
User source for each input.
4) Output Mixer: Set the microphone mixing mode of the unit.
■
Mixer O: Disable the audio mixer.
■
Mixer On: Enable the audio mixer. Audio from the current source
and the microphone will be mixed together.
■
MIC Only: Output only the microphone audio source. This mode
will override all other audio selections.
Note: Activating Mixer On mode, or MIC Only mode will automatically
disable HDMI Out Bypass mode.
