48
Note: If the IP address is changed then the IP address required for
WebGUI/Telnet access will also change accordingly.
Web Login Timeout (Minutes): Set the length of time to wait, in
minutes, before logging out a user due to inactivity. Setting it to 0
means there is no timeout.
Network Reset: Reset all Ethernet settings back to their factory
defaults.
2) Trigger Configuration: Use each dropdown to set the unit’s action, if
any, when each trigger is activated.
3) Backup & Restore:
Backup: The current system configuration, including routing and
settings, may be saved as a JSON file to a PC. Click the “Backup”
button to save the current system configuration to your local PC.
Restore: Previously saved system configurations may be restored
from a saved JSON file. Click the “Restore” button to open the file
selecting window and then select the saved JSON file located on
your local PC. After selecting the file, click the “Open” button to
import the new configuration.
4) Advanced Settings:
Firmware Version: Displays the unit’s firmware version.
CMD Version: Displays the unit’s command version.
Firmware Upgrade: To update the unit’s firmware, click the “Upload
Firmware” button to open the file selection window and then select
the firmware update file (*.bin format) located on your local PC.
After the upgrade is complete, the unit will reboot automatically.
Serial Number: Displays the unit’s serial number.
Device Nickname: To change the name of the unit, type the new
name in the space provided, then click on the “Apply” button.
Virtual Keyboard: If a keyboard is not available, an on-screen
keyboard can be enabled or disabled here. This setting synchronize
with the “Virtual Keyboard” icon (
) on the top right corner of the
page.
Login Destination: Define the landing page after user login
successfully. Selecting “Home Page” will direct the user to the home
page, while selecting “Main Page” will take them to Video Routing
Page.
