6
1. INTRODUCTION
This scaler has DisplayPort, HDMI and PC (VGA) inputs which can be freely
selected for output at a scaled resolution of the user’s choosing over the
mirrored HDMI and HDBaseT outputs. This unit also includes separate
analogue and digital audio outputs to provide additional playback ex-
ibility. Support for HDMI output resolutions up to 1080p/WUXGA (RB) and
Analogue to Digital Conversion (ADC) functionality combine to allow for a
wide range of AV signals to be displayed on the connected HDMI displays.
Beyond video switching and scaling, this unit also features useful audio
functions. The Optical Audio Return (OAR) feature supports transmitting
optical audio from a compatible HDBaseT Receiver to this unit for local
playback. An integrated audio DSP with gain control for routing audio
and controlling background audio levels adds to the versatility of this
product. The HDBaseT output can provide 48V PoH to power to compat-
ible HDBaseT Receivers. The unit can be controlled via front panel buttons
with an On-Screen Display (OSD), WebGUI, IR remote, Telnet, and RS-232
making it exceptionally versatile.
2. APPLICATIONS
Analogue and Digital source integration
Upscaling standard denition sources for high-denition displays
Conference centers
Lecture halls
Schools and universities
3. PACKAGE CONTENTS
1×HDMI/DP/VGA to HDMI/HDBaseT Scaler (PSE) with OAR
1×24V/2.7A DC Power Adapter
1×Power Cord
1×3.5mm to IR Extender Cable
1×3.5mm to IR Blaster Cable
1×Remote Control (CR-176)
1×Operation Manual
