32
STATUS
This section provides information about the unit’s current input, output
and HDCP status as well as the current Firmware Revision.
VIDEO
This section allows for control of input selection, output resolution &
aspect ratio, HDCP behavior for the HDMI & DisplayPort inputs, the “no
signal” colour, blanking or freezing the output, as well as configuring the
auto switch and sync functionality of the unit.
Colour
This section provides detailed controls for the output R/G/B levels,
contrast, saturation, brightness, hue, and sharpness as well as controlling
noise reduction. To return these settings to their defaults, click on the
“Reset Picture” EXE button.
VGA
This section allows for direct control of the H-position, V-position,
phase, and clock used by the current VGA input. These settings can be
automatically configured by clicking on the “Auto Setup” EXE button. To
return these settings to their defaults, click on the “Reset” EXE button.
Note: The VGA section is only active when a live VGA source is currently
selected. These settings are shared by both VGA inputs.
EDID
This section allows the user to choose the EDID to be used with each
input. It is also possible to upload custom user EDIDs here. User EDIDs 1-3
are only usable by the HDMI and DisplayPort inputs. User EDIDs 4-5 are
only usable by the VGA inputs.
6.6.2 Main Page 1
Select the “MainPage1” tab to adjust settings related to audio output,
the OSD, Ethernet, and power. System reset, authentication changes
and firmware updates may also be performed from here. If desired, the
numerical value for many of the items can be entered directly by typing it
in the box above the slider bar. Press “Enter” to accept the newly entered
value.
