8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
HDCP2.2
+
POWER SYNC
UHD 4 TO 1 SWITCHER
INPUT 1234
1 2 53 4 6
2
IR WINDOW: Accepts IR signals from the included IR remote for
control of this unit only.
2
POWER: Press this button to power on the unit or place it into stand-
by mode.
Note: Ethernet and RS-232 remain active while the unit is in stand-by
mode.
2
POWER LED: The LED will illuminate RED to indicate the unit is
receiving power but is in stand-by mode. It will illuminate GREEN to
indicate that the unit has been turned on.
2
SYNC LED: This LED will illuminate GREEN when a stable connection
with an output device is detected.
2
INPUT: Press this button to sequentially switch through the 4 available
inputs.
2
INPUT LED 1~4: These LEDs will illuminate GREEN to indicate which
of the 4 sources are currently selected.
Bekijk gratis de handleiding van CYP EL-41HP-4K22, stel vragen en lees de antwoorden op veelvoorkomende problemen, of gebruik onze assistent om sneller informatie in de handleiding te vinden of uitleg te krijgen over specifieke functies.
Productinformatie
| Merk | CYP |
| Model | EL-41HP-4K22 |
| Categorie | Niet gecategoriseerd |
| Taal | Nederlands |
| Grootte | 1840 MB |
Caratteristiche Prodotto
| Kleur van het product | Zwart |
| Gewicht | 1300 g |
| Breedte | 219 mm |
| Diepte | 156 mm |
| Hoogte | 43 mm |
