8
6. OPERATION CONTROLS AND FUNCTIONS
6.1 Front Panel
SERVICE SWITCH MODE AUDIO INFO.
POWER
EL-21PIP
1 2 3 4 5 6
1
SERVICE: This port is reserved for firmware update use only.
2
POWER LED: This LED will illuminate to indicate the unit is on and
receiving power.
3
SWITCH Button: Press to toggle between the two HDMI inputs and
output the selected source full screen.
Note: Press and hold this button for 2 seconds to change the output
resolution to 1920×1080p@60Hz.
4
MODE Button: Press to sequentially switch between the Full Screen
(NONE), Picture-in-Picture (PIP), Side-by-Side (SBS), and Picture-
outside-Picture (POP) windowing modes.
Note: Press and hold this button for 2 seconds to change the output
resolution to 1024×768@60Hz.
5
AUDIO Button: Press to toggle between the audio from the 2 HDMI
inputs.
6
INFO. Button: Short press to show the current input/output
resolution status, audio selection and IP information. Long press to
show the current contrast, brightness, hue, sharpness, colour format,
chroma and colour temperature settings for each source channel.
