6
1. INTRODUCTION
This HDMI Multiviewer is capable of scaling up to 2 sources and displaying
both simultaneously on a single HDMI output within their own windows.
This is the ideal solution for monitoring multiple sources simultaneously
for use in control rooms, or for exible display presentations in
conference rooms or classrooms. Both inputs support resolutions up to
1920×1200@60Hz and LPCM audio with up to 7.1 channels at 192kHz.
The multi-window output is sent to a single HDMI output at scaled
resolutions up to 1920×1200@60Hz along with the selected audio
source. The HDMI output supports up to LPCM 7.1 digital audio while
the analogue audio output supports up to LPCM 2.0. Each of the 2
HDMI sources may be displayed individually, full screen, or they can be
displayed using a variety of dual-window modes including Picture-in-
Picture, Side-by-Side, or freely positioned (with layer priority control).
Each window can also be mirrored, ipped, swapped, or frozen (with live
audio). Chromakeying and a custom uploadable logo/graphic are also
supported.
By using an optional Windows PC application, the user can use their PC to
generate images or text to be overlaid on top of a live HDMI input in real
time. This unit can be controlled easily by use of the front panel controls
(with OSD) as well as by WebGUI, Telnet, RS-232, IR, and 8 direct trigger
inputs.
2. APPLICATIONS
Demo Room Displays
Security Monitoring
Hotel Lobby Information Displays
3. PACKAGE CONTENTS
1×HDMI Multiviewer
1×5V/2.6A DC Power Adapter
3×5-pin Terminal Block
1×Shockproof Feet (Set of 4)
1×Operation Manual
