21
EN
The minimum distance between the supporting surface for
the cooking equipment on the hob and the lowest part of the
range hood must not be less than 50cm from electric cookers
and 65cm from gas or mixed cookers. If the instructions for
installation for the gas hob specify a greater distance, this
must be adhered to.
ElECtriCal CoNNECtioN
The mains power supply must correspond to the rating indi-
cated on the plate located inside the hood. If provided with
a plug connect the hood to a socket which is in compliance
with current regulations and located in an easily accessible
area. If it is not tted with a plug (direct mains connection)
or if after installation the plug is not located in an accessible
area, apply a double pole switch in accordance with standards
which assures the complete disconnection of the mains under
conditions relating to over-current category III, in accordance
with installation instructions.
Warning! Before re-connecting the hood circuit to the mains
supply and checking the ecient function, always check that
the mains cable is correctly assembled.
The hood is provided with a special power cable; if the cable is
damaged, request a new one from Technical Service.
Expansion wall plugs are provided to secure the hood to most
types of walls/ceilings. However, a qualied technician must
verify suitability of the materials in accordance with the type
of wall/ceiling. The wall/ceiling must be strong enough to take
the weight of the hood. Do not tile, grout or silicone this appli-
ance to the wall. Surface mounting only.
This appliance is designed to be used either for exhausting or
lter version. The models with no suction motor only operate
in ducting mode, and must be connected to an external suc-
tion device (not supplied).
The connecting instructions are supplied with the peripheral
suction unit.
Installation
Mounting
Use
In this case the fumes are conveyed outside of the building by
means of a special pipe connected with the connection ring
located on top of the hood.
Attention! The exhausting pipe is not supplied and must be
purchased separately.
Diameter of the exhausting pipe must be equal to that of the
connection ring. In the horizontal runs the exhausting pipe
must be slightly slanted (about 10°) and directed upwards to
vent the air easily from the room to the outside. Attention! If
the hood is supplied with active charcoal lter, then it must
be removed.
Connect the hood and discharge holes on the walls with a
diameter equivalent to the air outlet (connection ange).
Using the tubes and discharge holes on walls with smaller di-
mensions will cause a diminution of the suction performance
and a drastic increase in noise.
Any responsibility in the matter is therefore declined.
! Use a duct of the minimum indispensible length.
! Use a duct with as few elbows as possible (maxi-
mum elbow angle: 90°).
! Avoid drastic changes in the duct cross-section.
! Use a duct with an as smooth as possible inside.
! The duct must be made of certied material.
In this work mode the hood extracts and cleans the air from
the kitchen and after that the air is sent back to the room. In
order for the device to work properly an additional lter (or
lters) must be installed. The lter utilizes active charcoal for
air purication and can be obtained from your nearest retailer.
The lter removes the grease and smells from the extracted
air before sending it back into the room through the upper
outlet grid.
A control panel is used to operate the appliance. Depending
on the model that you have purchased there are two possible
types of control.
Ducting version
Operation
