Do not install the hob above the oven without ventilation.
INSTALLATION
Making the worktop recess
• Worktop thickness should be 28 - 40 mm, while its width at least 600 mm. The worktop
must be at and level. Edge of the worktop near the wall must be sealed to prevent in-
gress of water or other liquids.
• There should be sucient spacing around the opening, in particular, at least 50 mm di-
stance to the wall and 60 mm distance to the front edge of worktop.
• The distance between the edge of the opening and the side wall of the furniture should
be at least 55 mm.
• Worktop must be made of materials, including veneer and adhesives, resistant to a tem-
perature of 100°C. Otherwise, veneer could come o or surface of the worktop become
deformed.
• Edge of the opening should be sealed with suitable materials to prevent ingress of water.
• Worktop opening must cut to dimensions as shown on gure 1.
1
