Connection to an automatic dosing system
The dishwasher can be connected to one or more systems for the automated dosage of commercial
detergent and rinse aid, which simplifies everyday operation and reduces the risk of overdosing.
Connection to a system for automated dosage must be performed by the supplier of the system or
by somebody with an equivalent professional qualification.
WARNING!
Danger of contact with high voltage! Remove the plug from the wall socket.
Connect the cables
Connect the hoses
Connect the cables
Connect the external cables for automated dosage to the back of the dishwasher.
The length of the external cables must not exceed 3.0 m.
1. Loosen the screw to remove the protective cover.
2. Connect the external cables for detergent to the auto dose connector.
A Connection for earth
B Connection for level sensor
C Connection for impulse of
detergent (230V)
3. Connect the external cables for rinse aid to the auto dose connector.
40
