25
Operation
Remote Management
The remote management function provides monitoring of the PDU
operational information, controlling outlets and utilizing SNMP
functionality.
Web
Remote management can be performed via web interface. To access
the web interface, please follow the instructions below:
1. Enter the IP address of the PDU into a web browser.
2. Enter the user name and password of the PDU device at the
authentication screen.
Note: The default username is “cyber” and the default password is
“cyber”.
For additional information about the features and functionality of
CyberPower Management Console, please refer to the Intelligent
PDU Web Interface User’s Manual available for download from
www.cyberpower.com.
Telnet and SSH
The CyberPower PDU provides Telnet and Secure Shell (SSH) as Remote
Management methods. Telnet uses user name and password as basic
security while SSH has a higher security level with encryption of the
transmitted packets including user name, password, and data. Configure
the Setting of Telnet and SSH on the Web Interface. The default user
name and password is cyber; cyber.
SNMP
The CyberPower PDU supports SNMPv1 and SNMPv3 protocols.
Download the CyberPower MIB file from www.cyberpower.com and
add it to an SNMP-supported management software. Default read/
write community is public/private for SNMPv1. SNMPv3 provides a
higher security level than SNMPv1 by encrypting the transmitted packet.
Configure the settings of the SNMPv1/SNMPv3 on Web Interface.
Local Management
LCD Operation
The LCD screen provides instant information, such as voltage, current
and power, for the PDU. In addition, users can use the interface
to configure each PDU parameters and control each outlet on the
Switched PDU. The LCD detects the installation orientation of the PDU
(horizontally or vertically), therefore automatically rotates the screen to
best fit the reading direction.
A. Scroll Mode: The PDU information will display in following order
automatically when “Scroll Mode On” is configured.
Device Information
Phase L1 (input source Wye) , Phase L1-2 (input source Delta)
Phase L2 (input source Wye) , Phase L2-3 (input source Delta)
Phase L3 (input source Wye) , Phase L3-1 (input source Delta)
Voltage (Display if device input source is WYE, and has phase to phase outlet.)
Bank 1-N Information (Displays if device has N circuit breakers)
Environment Status (Displays when the ENVIROSENSOR is connected)
Alert
B. Main Menu Map
Alert
Current
Log
Meter
Device
Phase
Bank
Outlet
Control
Device
Immediate On
Delay On
Phase 1/2/3 or
Phase L1-2/L2-3/L3-1
Immediate Off
Delay Off
Bank 1-N
Reboot
Delay Reboot
Outlet 1-N
Setting
LCD
Color
Brightness
Direction
Screen off
Reset
Account (User Name
and Password)
Except TCP
To Default
Reboot
About
Model Name
Serial Number
Network
Daisy Chain (Displays when the PDUs are connected)
Hardware Version
Firmware Version
