9Curtis Instruments enGage
®
VII Manual
Pin No. Signal Description
J1-1 Battery Voltage (B+)
J1-2 Battery Common (B-)
J1-3 Keyswitch
J1-4 CAN High
J1-5 CAN Low
J1-6 CAN Shield
J1-7 CAN_Term1
J1-8 CAN_Term2
J1-9 1311 RX
J1-10 CAN Common
J1-11 1311 TX
J1-12 LCD Heater B+
J3-1
1
MOSFET 3 & 4 Common
J3-2 Frequency Input 3
J3-3 MOSFET Output 3
J3-4 MOSFET Output 4
J3-5 Switch Input 9
J3-6 Switch Input 10
J3-7 Switch Input 11
J3-8 Switch Input 12
J3-9 Switch Input 13
J3-10 Switch Input 14
J3-11 Switch Input 15
J3-12 Switch Input 16
J3-13 Sender 4
J3-14 Potentiometer High
J3-15 Sender 5
J3-16 Potentiometer Low
Pin No. Signal Description
J2-1 Sender 1
J2-2 No Connect
J2-3 Switch Input 1
J2-4 Switch Input 2
J2-5 Switch Input 3
J2-6 Switch Input 4
J2-7 No Connect
J2-8 Backlight Dimmer Input
J2-9 Frequency Input 1
J2-10 MOSFET Output 1
J2-11 MOSFET Output 2
J2-12
1
MOSFET 1 & 2 Common
J2-13 Switch Input 5
J2-14 Switch Input 6
J2-15 Switch Input 7
J2-16 Switch Input 8
J2-17 Sender 2
J2-18 No Connect
J2-19 Sender 3
J2-20 Frequency Input 2
1
MOSFET common signals J2-12, J3-1 must
be connected to B– externally.
Table 8 Video Input Connector
Pin No. Signal Description
1 Video Input Ground
2 Video Input 1 Signal
3 Video Input 2 Signal
Optional Mating Harness Assemblies (connectors with ying leads and butt splices)
• Connector J1: 15233014-1
• Connector J2: 15233014-2
• Connector J3: 15233014-3
• Connector J4: 15233014-4
Table 7 Module Product, Model 3701P AMP I/O Connector Signals
