Curtis enGage VII handleiding
Handleiding
Je bekijkt pagina 7 van 24
7Curtis Instruments enGage
®
VII Manual
Pin No. Signal Description Pin No. Signal Description
J1-1 Battery Voltage (B+) J2-1 Sender 1
J1-2 Battery Common (B-) J2-2 No Connect
J1-3 Keyswitch J2-3 Switch Input 1
J1-4 CAN High J2-4 Switch Input 2
J1-5 CAN Low J2-5 Switch Input 3
J1-6 CAN Shield J2-6 Switch Input 4
J1-7 CAN_Term1 J2-7 No Connect
J1-8 CAN_Term2 J2-8 Backlight Dimmer Input
J1-9 1311 RX J2-9 Frequency Input 1
J1-10 CAN Common J2-10 MOSFET Output 1
J1-11 1311 TX J2-11 MOSFET Output 2
J1-12 LCD Heater B+ J2-12
1
MOSFET 1 & 2 Common
J3-1 Switch Input 5 J4-1 Switch Input 9
J3-2 Switch Input 6 J4-2 Switch Input 10
J3-3 Switch Input 7 J4-3 Switch Input 11
J3-4 Switch Input 8 J4-4 Switch Input 12
J3-5 Sender 2 J4-5 Switch Input 13
J3-6 No Connect J4-6 Switch Input 14
J3-7 Sender 3 J4-7 Switch Input 15
J3-8 Frequency Input 2 J4-8 Switch Input 16
J3-9
1
MOSFET 3 & 4 Common J4-9 Sender 4
J3-10 Frequency Input 3 J4-10 Potentiometer High
J3-11 MOSFET Output 3 J4-11 Sender 5
J3-12 MOSFET Output 4 J4-12 Potentiometer Low
Table 5 Cased / Enclosed Product, Model 3701T Deutsch I/O Connector Signals
1
MOSFET common signals J2-12, J3-9 must be connected to B– externally.
