5Curtis Instruments enGage
®
VII Manual
Panel Cutout Detail
R378.0±0.5
144.5±0.5
71.0±0.5
30.0±0.5
168.0±0.5
168.0±0.5
178 .0±0.5
R10.0±0.5
R10.0±0.5
R4.0±0.5
R4.0±0.5
119. 0
90.0
BUTTONS:
DETAIL “A”
“LEFT” “UP” “SELECT” “DOWN” “RIGHT”
OVERMOLD OVERMOLD
8.8±1.0
6.0±1.0
71.7±1.0
59.7±1.0
2
V
I
D
E
O
I
N
1 6 1 6
12 J2 7
1 6
12 J4 7
1 6
12 J3 7
12 J1 7
152.0±1.0
190.4±1.0
Panel
0.8−2.5mm
2.0−2.5mm 2.0−8.0mm
>2.5mm
FIGURE 1 FIGURE 2 FIGURE 3
Panel
Panel
Optional Undercut
Optional Mounting
Bracket 17687370
Mounting Options
NOTE: Mounting bracket 17687370 can be used for panel thicknesses 2.0–8.0mm. Mounting bracket is
designed for one installation only. Destruction of mounting bracket may occur if attempted to remove.
