3 — INSTALLATION, WIRING AND CONFIGURATION
pg. 15
Return to TOC Curtis Model 3150R – April 2025
I/O CONNECTOR
e mating connector is an 8-pin Mini-Universal MATE-N-LOK housing from TE Connectivity.
e front and rear are sealed to IP67 for electronic components and IP40 for the connector. You can
increase the connector’s protection to IP54 by using the parts listed in Table 3-2.
e following tables list the TE Connectivity parts for IP40 and IP54 protection.
Table 3-1 Mating Connector Parts—IP40 Protection
Part TE Connectivity Part Number
Connector Housing 770579-1
Terminal (18–22 AWG) 770904-X
Table 3-2 Mating Connector Parts—IP54 Protection
Part TE Connectivity Part Number
Connector Housing 794821-1
Terminal (18–22 AWG) 770904-X
Interface Seal 794772-8
Single Wire Seal or Gang Seal 794758-1 or 1586359-8
Cavity Plug Seal (for unused
terminal positions)
794995-1
I/O PINS
e following table describes the I/O pins.
Pin Signal Name Description
1 CAN Low CANbus low signal
2 CAN High CANbus high signal
3 B− Battery negative
4 B+ Battery positive
5 SCI Tx / SW1 Serial communication interface Tx or Switch 1
Note: Some models use pins 5–6 for a serial
port, other models use these pins for Switch 1
and Switch 2.
6 SCI Rx / SW2 Serial communication interface Rx or Switch 2
7 KSI Keyswitch
8 Lift Lockout Output / SW3 Lift lockout output or Switch 3
