6 — PROGRAMMABLE PARAMETERS

Curtis Electronic Code Switch Module (ECS) – June 2022 Return to TOC

pg. 16

6 — PROGRAMMABLE PARAMETERS

LOGON USER MANAGEMENT MENU..... p.18

— Logon User ID

— Logon User Name Code

— Logon RFID 1

— Logon RFID 2

— Logon RFID 3

LOG ON USER SETUP MENU......... p.19

— New PIN Code

— Save New PIN Code

— New RFID Tag

— Delete RFID Tag

— New Name Code

— Save New Name Code

SUPERVISOR MANAGEMENT MENU..... p.20

— First Free User ID

— Target User ID

— Target User State

— Create Target User PIN Code

— Create Target User RFID Tag

— Delete Target User

USER INFORMATION MENU............... p.21

— Last Logon User ID

— Total Registered Users

REGISTERED USER LIST MENU.... p.21

SUPERVISOR MENU................ p.21

— User Status

— User Name Code

USER 01—USER 99 MENUS... p.21

— User Status

— User Name Code

APPLICATION SETUP MENU............... p.22

CONTROL MENU........................... p.22

— Interlock Type

— Interlock High Threshold

— Mute Enable

— Logoff Time

— RFID Swipes Logoff Enable

RELAY MENU................................ p.23

— Relay Work Mode

— Pull-in Voltage

— Holding Voltage

— Open Delay

— Relay Driver

— Relay Driver PWM

— Relay Driver Feedback

CAN INTERFACE MENU................. p.24

— Baud Rate

— Node ID

— Heartbeat Rate

— Auto Operation

— CAN NMT State

RPDO1—RPDO4 SETUPS MENUS.... p.25

— RPDOn Event Time

— RPDOn COB ID

RPD O1—RPDO4 SETUPS

MENUS.............................. p.25

— Length

— Map 1 through Map 8

TPDO1—TPDO4 SETUPS MENUS.... p.25

— TPDOn Event Time

— TPDOn COB ID

TPD O1—TPDO4 MAPPING

MENUS.............................. p.25

— Length

— Map 1 through Map 8

MISC MENU.................................. p.28

— Restore Parameters

— AM Base Calibration

— Pass Through Switch

PASS THROUGH MODE MENU........... p.29

— Input PushButton Value

— Clear PushButton Value

— RFID 0

— RFID 1

— RFID 2

— Clear RFID Input Value

— Receive RFID Input Only

— Tone Control Enable via CAN

— LED Control Enable via CAN
