2 — USING THE 3401T
pg. 19
Return to TOC Curtis Model 3401T – August 2022
e Warning and Low gauges ash when they are active. If the BDI percentage is too low, li lockout
is activated and the icon displays.
Speedometer
The speedometer displays the speed in km/h or mph, depending upon how the device is
configured. The speedometer on the reach trucks and order pickers screen may also display a
speed limit. The following figures show how the preset user interfaces display the speedometer:
Figure 2-3
Speedometer —
Counterbalanced
Forklis
5
0
10
25
30
20
15
10.2
km/h
Figure 2-4
Speedometer —
Reach Trucks and
Order Pickers
10.2
km/h
(MAX 20.0)
Hour Meters, Cargo Weight and Lift Height
e hour meters, cargo weight and li height area displays up to two of the following items at any
given time:
Icon Hour Meter
00186.9
P
Pump controller hour meter
00122.8
T
Traction controller hour meter
001234
Kg
Cargo weight
010.500
m
Lift height
These indicators may be displayed in any combination, such as the combinations in the
following examples:
00122.8 T
00186.9
P
010.500
m
00122.8
T
010.500
m
001234
Kg
001234
Kg
00122.8
T
