4 — PROGRAMMABLE PARAMETERS
Curtis Model 3301T – August 2022 Return to TOC
pg. 40
OUTPUT MENU
e Output Mode parameter species how pin 8 (Switch Input5/MOSFET OUTPUT) is used. e
Driver Output Setting parameter and the parameters on the following submenus apply when the
pin is used as a driver:
• Ramp
• Initial
• Current Limit
• Dither
• PI
OUTPUT MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
Output Mode
0x6620:00
Enumerated
0–5
16-bit OEM Dealer
4
Species the function for pin 8:
0 = Turn Off.
1 = PWM Mode.
2 = Voltage Mode.
3 = Current Mode.
4 = Lift Lock Mode.
5 = Switch Input Mode.
Driver Output Setting
0x66F0:00
0.0–100.0%
0–1000
16-bit OEM Dealer
0.0%
Species the output when pin 8 is used as a driver.
How the parameter is used depends upon the
Output Mode:
• PWM mode: The actual duty cycle.
• Voltage mode: The product of this value and
the Nominal Voltage parameter is the actual
output voltage.
• Current mode: The product of this value and
the Maximum Current parameter is the actual
output current.
Ramp Menu
e following table describes the parameters on the Ramp menu.
RAMP MENU
PARAMETER
CAN INDEX
VALUES
RAW VALUES DATA SIZE
ACCESS LEVEL
DEFAULT VALUE DESCRIPTION
Ramp Up Time
0x6650:00
0–10000ms
0–10000
16-bit OEM Dealer
8ms
Species the time it takes to go from minimum to
maximum output current.
Ramp Down Time
0x6660:00
0–10000ms
0–10000
16-bit OEM Dealer
8ms
Species the time it takes to go from maximum to
minimum output current.
