2 — USING THE 3301T
Curtis Model 3301T – August 2022 Return to TOC
pg. 16
Figure 3
Reach Trucks and Order Pickers Application — 3301T-7001
e following table describes the areas contained by the home screens. Unless otherwise indicated,
these areas are contained by both home screens.
Table 2 3301T-7001 Home Screen Areas
Number Area
1 Speed mode.
2 Signal icons.
3 Direction.
4 BDI.
5 Speedometer.
6 Cargo weight and lift height (counterbalanced forklifts application only).
7 Controller hour meters.
8 Keyswitch hour meter.
9 Steering angle (counterbalanced forklifts application only).
10 Fault codes.
11 Forklift status (reach trucks and order pickers application only).
12 Steering angle (reach trucks and order pickers application only).
e following topics describe these areas.
