40
Curtis 1356/1356P CAN Expansion Module Manual, Rev. A
6 — DIAGNOSTICS & TROUBLESHOOTING
Fast
Red
LED
Table 5 TROUBLESHOOTING CHART
CODE FAULT DESCRIPTION EFFECT RECOVERY
Corrupt Code 1356 /1356P in corrupted state.
1356 /1356P in Fault Requires repair or new
state. software download.
11 Internal Fault Encryption failure.
1356 /1356P in Stopped
Requires repair and ATS test.
state.
12 Flash Fault
Flash did not properly write or
All outputs stopped.
Write to failed location and
Checksum did not match. cycle KSI.
21 Over Voltage
Battery over limit.
All outputs stopped.
Battery returns to normal
Limit = (Nominal Voltage * 1.25) + 5V. range for >1 second.
Battery under limit.
Limit = (Nominal Voltage * 0.7)
Battery returns to normal
22 Under Voltage - 5V when Nominal Voltage ≥24V. All outputs stopped.
range for >1 second.
Limit = (Nominal Voltage * 0.7)
- 0.6V when Nominal Voltage =12V.
31 Driver1 Fault
Driver 1 is in overcurrent (>3.5 amps).
Output on the faulted Send a 0% PDO command
32 Driver2 Fault
Driver 2 is in overcurrent (>1.5 amps).
driver stopped.
to the faulted driver.
Driver 1 output pin is low when driver
33 Coil1 Fault is O. is implies the pin has been
left open. Output on the faulted
Driver 2 output pin is low when driver
driver not functional.
34 Coil2 Fault is O. is implies the pin has been
left open
41 PDO Timeout
PDO from master has not been All drivers disabled New PDO received within
received within the time-out period. and commands cleared. proper timing.
1356 /1356P in Stopped
NMT received, or bus
42 CAN Bus Fault Too many CAN bus errors detected.
state.
reception & transmission
restored.
43 Encoder Fault Encoder wire open. Encoder count stopped. Cycle KSI.
44 EEPROM Fault e EEPROM did not properly write. None. Write to failed location.
45 Analog Input Analog input exceeds 15.5V (voltage
None.
Bring analog input within
Fault
input) or 7.5kΩ (resistance input). range.
51 5V Supply Fail
External load impedance on
None. Bring voltage within range.
+5V Supply is too low.
52 12V Supply Fail
External load impedance on
None. Bring voltage within range.
+12V Supply is too low.
53 External Supply External load on +5V and +12V
None.
Bring external supply current
Out of Range
exceeds 200 mA. within range.
Driver pin is reconnected.
