Curtis 1356/1356P CAN Expansion Module Manual, Rev. A
29
5 — SDO: Communication Profile Objects
Table 2 Communication Prole Object Dictionary, cont’d
range
name access index sub-index can value description
PDO1-MISO mapping for the 3rd
PDO1-MISO
RW 0x1A00 0x03 N/A
application object to be mapped.
Mapping 3rd Default mapped to LSB byte of
Virtual Digital Input States.
PDO1-MISO mapping for the 4th
PDO1-MISO
RW 0x1A00 0x04 N/A
application object to be mapped.
Mapping 4th Default mapped to MSB byte of
Virtual Digital Input States.
PDO1-MISO mapping for the 5th
PDO1-MISO
RW 0x1A00 0x05 N/A
application object to be mapped.
Mapping 5th Default mapped to LSB byte of
Analog4 Voltage Value.
PDO1-MISO mapping for the 6th
PDO1-MISO
RW 0x1A00 0x06 N/A
application object to be mapped.
Mapping 6th Default mapped to MSB byte of
Analog4 Voltage Value.
PDO1-MISO mapping for the 7th
PDO1-MISO
RW 0x1A00 0x07 N/A
application object to be mapped.
Mapping 7th Default mapped to LSB byte of
Analog5 Voltage Value.
PDO1-MISO mapping for the 8th
PDO1-MISO
RW 0x1A00 0x08 N/A
application object to be mapped.
Mapping 8th Default mapped to MSB byte of
Analog5 Voltage Value.
PDO2-MISO Mapping RO 0x1A01 0x00 N/A
Number of mapped application
objects in PDO2-MISO.
PDO2-MISO mapping for the 1st
PDO2-MISO
RW 0x1A01 0x01
N/A
application object to be mapped
Mapping 1st Default mapped to LSB byte of
Analog1 Voltage Value.
PDO2-MISO mapping for the 2nd
PDO2-MISO
RW 0x1A01 0x02
N/A
application object to be mapped
Mapping 2nd Default mapped to MSB byte of
Analog1 Voltage Value.
PDO2-MISO mapping for the 3rd
PDO2-MISO
RW 0x1A01 0x03 N/A
application object to be mapped
Mapping 3rd Default mapped to LSB byte of
Analog2 Voltage Value.
PDO2-MISO mapping for the 4th
PDO2-MISO
RW 0x1A01 0x04 N/A
application object to be mapped
Mapping 4th Default mapped to MSB byte of
Analog2 Voltage Value.
PDO2-MISO mapping for the 5th
PDO2-MISO
RW 0x1A01 0x05 N/A
application object to be mapped
Mapping 5th Default mapped to LSB byte of
Analog3 Voltage Value.
PDO2-MISO mapping for the 6th
PDO2-MISO
RW 0x1A01 0x06 N/A
application object to be mapped
Mapping 6th Default mapped to MSB byte of
Analog3 Voltage Value.
