2 — INSTALLATION SPECIFICATIONS AND WIRING
pg. 9
Return to TOC Curtis Model 1351 – February 2024
Pin Driver Output Digital Input
Analog Input
(Range)
Special or
Dedicated Usage
Related VCL*
Function References
10 + 5V (Output)
Control_External_
Power()
Ext_5V
Ext_5V_Current
CIT/1313 HHP Programmer:
Configuration\System Controller\External Supplies
11 Safety Output Coil Return Put_Driver( ) Safety_Output_State
12 Safety Output Coil Return Put_Driver( ) Safety_Output_State
13 PWM Driver 1 Switch Input 1 Proportional
Automate_Driver( )
Put_Driver( )
Setup_Ramp( ), Etc.
Driver_1_PWM
Driver_1_Current
Switch_1
CIT/1313 HHP Programmer:
Configuration\Outputs\PWM Drivers\Driver1
Configuration\Inputs\Switches\SW 1
14
High Speed Input 1
Virtual Switch 3
Analog 3 (0-5V) Encoder 1B reset_pulse_counter( )
Virtual_Switch_3
Analog_3_Volts
Encoder_1_RPM
Encoder_1_Position
CIT/1313 HHP Programmer:
Configuration\Inputs\Virtual Switches\VSW 3
Configuration\Inputs\Analog Inputs
Configuration\Inputs\High Speed Inputs
Configuration\Inputs\Encoder Inputs
15
High Speed Input 2
Virtual Switch 4
Analog 4 (0-5V) Encoder 1A reset_pulse_counter( )
Virtual_Switch_4
Analog_4_Volts
Encoder_1_RPM
Encoder_1_Position
CIT/1313 HHP Programmer:
Configuration\Inputs\Virtual Switches\VSW 4
Configuration\Inputs\Analog Inputs
Configuration\Inputs\High Speed Inputs
Configuration\Inputs\Encoder Inputs
16 Virtual Switch 5 Analog 5 (0-20V) RTD 1
Virtual_Switch_5
Analog_5_Volts
RTD_1_R
RTD_1_OUT
CIT/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\RTD Input
Configuration\Inputs\Virtual Switches\VSW 5
17 Virtual Switch 6 Analog 6 (0-20V) RTD 2
Virtual_Switch_6
Analog_6_Volts
RTD_2_R
RTD_2_OUT
CIT/1313 HHP Programmer:
Configuration\Inputs\Analog Inputs
Configuration\Inputs\RTD Input
Configuration\Inputs\Virtual Switches\VSW 6
Table 2 Low Current Connections, cont’d
