2 — INSTALLATION AND WIRING
Curtis Model 1226BL – July 2024 Return to TOC
pg. 22
e following table describes the specications for the external power supply outputs:
Specification +5V Supply +14V Supply
Nominal Output 5.2V 14V
Output Range 4.5V~6.0V 12V~16.5V
Maximum Current 50mA 70mA
Maximum Voltage Depends upon the model:
• 1226BL-22XX and 1226BL-41XX: 63V
• 1226BL-61XX: 105V
Maximum Reverse Voltage −1V
Hydraulic Pump Contactor Driver
1226BL-22XX and 1226BL-41XX models provide a driver for a hydraulic pump contactor. If the
vehicle includes a hydraulic pump that will be managed by the controller, connect it to pin J3-11.
To configure the driver, use the parameters on the Drivers Setting Menu that begin with the
word “Pump”.
For the driver’s specications, see Table 2.
Main Contactor Driver
1226BL-61XX models provide a driver for a main contactor.
If the controller will be driving a main contactor, use pin J3-11 for the driver output. e Main Enable
parameter species whether the controller drives a main contactor; see Main Relay Menu.
e Main Relay menu also contains parameters for conguring the following:
• Contactor opening delay
• PWM mode
• Pull-in and holding voltages
• Precharge
• Whether the controller checks the driver for the open condition
For the driver’s specications, see Table 2.
Forward and Reverse Switches
If the vehicle uses a dual switch throttle, connect the reverse switch to pin J3-8 and the forward
switch to pin J3-17.
